Air Make-up Systems (AMS)

Two-stage or full modulation direct fired air make-up system designed for use on automotive spray booths. Damper in the system allows for multiple passes through the furnace resulting in higher temperature rise in the bake cycle.

Two-stage or variable frequency drive, direct fired air make-up system designed for use on automotive spray booths. Variable frequency drive allows for additional heating adjustment during the bake cycle.

Indirect fired air make-up system designed for use on automotive spray booths. This air make-up system is designed for milder and warmer climate where small temperature rise is required.

Fresh air make-up system designed for balancing the air pressure inside spray booths. This system has no heating and is used to provide positive pressure to new or existing spray booths only.

The JetAir System is a cost effective, versatile system that significantly reduces the cure or dry time of both solvent and waterborne coatings. Reduce flash time of waterborne basecoat to as low as 2.5 minutes! Click on the link above or the picture to the left to view a brochure on the JetAir System.

This new system utilizes four fans mounted in the upper four corners of the spray booth, which circulate air in the booth during the cure.

In addition to the different air make-up systems, AFC also manufactures drying enclosures. Drying enclosures are designed to be used with your spray booth to improve the efficiency of your spray booth by enabling greater utilization of the spray booth itself. After the vehicle has been sprayed, it is moved into the drying enclosure where drying is carried on. The spray booth is immediately available to begin work on the next vehicle. The rate of production can be significantly increased by this system.
